Analog Devices' Wideband RF Power and Return Loss Measurement System Offers a Smaller Form Factor and Faster Time to Market

Analog Devices » ADL5920

Analog Devices introduced a 9 kHz - 7 GHz directional bridge and dual RMS RF power detector that can simultaneously measure forward and reverse RMS power levels in a signal path along with return loss. The new ADL5920 detector represents a change to conventional approaches by integrating a directional bridge-based coupler that results in an industry leading level of integration and bandwidth. For space-critical applications, the ADL5920 integrates the coupling or sensing function with the detection function and provides an output that can drive a precision analog-to-digital converter (ADC) directly. For wideband operation or for frequency variants, the ADL5920 detector eliminates the need to choose a different directional coupler for each frequency. This integrated, wideband device supports smaller form factors and faster product time to market.

Analog Devices - ADL5920

ADL5920 Product Highlights

  • Allows for coupled power measurements down to 9 kHz
  • Maximum input signal: +30 dBm with handling capability for open and shorted loads
  • Requires a 5 V supply and draws 150 mA
  • Supplied in a 32-lead, 5 mm × 5 mm LFCSP, for the operating temperature range of –40 °C to +85 °C
RFIN, RFOUT Typical Insertion Loss
RFIN, RFOUT Typical Insertion Loss.

Pricing and Availability

Product Sample
Availability
Full
Production
Price Each
Per 1,000
Packaging
ADL5920 Now December 2017 $14.50 5 mm × 5 mm LFCSP
