Datasheet LME49811TB/NOPB - National Semiconductor IC, AMP AUDIO 200 V 1CH TO247-15

Detailed Description

Manufacturer: National Semiconductor

Description: IC, AMP AUDIO 200 V 1CH TO247-15

Download Data Sheet

Docket:
LME49811 High Fidelity 200 Volt Power Amplifier Input Stage with Shutdown
January 4, 2008
LME49811 Audio Power Amplifier Series High Fidelity 200 Volt Power Amplifier Input Stage with Shutdown
General Description
The LME49811 is a high fidelity audio power amplifier input stage designed for demanding consumer and pro-audio applications.

Amplifier output power may be scaled by changing the supply voltage and number of output devices. The LME49811 is capable of driving an output stage to deliver in excess of 500 watts single-ended into an 8 ohm load in the presence of 10% high line headroom and 20% supply regulation. The LME49811 includes thermal shut down circuitry that activates when the die temperature exceeds 150°C. The LME49811's shutdown function when activated, forces the LME49811 into shutdown state.

Specifications:

• Amplifier Case Style: TO-247
• Amplifier Class: AB
• Base Number: 49811
• Load Impedance Min: 8 Ohm
• Load Impedance: 8 Ohm
• Mounting Type: Through Hole
• Number of Channels: 1
• Number of Pins: 15
• Operating Temperature Range: -40°C to +85°C
• Package / Case: TO-247
• SVHC: No SVHC (15-Dec-2010)
• Supply Voltage Range: ± 20 V to ± 100 V
• THD + N: 0.00055% @ VCC=50V

RoHS: Yes
