Datasheet Addendum XPP536156.250000I (IDT)
| Manufacturer | IDT |
| Description | 150fs Quartz-based PLL Oscillator |
| Pages / Page | 1 / 1 — 156.250000 MHz Crystal. XPP536156.250000I. Oscillator. Datasheet … |
| Revision | 20190520 |
| File Format / Size | PDF / 85 Kb |
| Document Language | English |
156.250000 MHz Crystal. XPP536156.250000I. Oscillator. Datasheet Addendum. General Configuration. Parameter. Value. Pin Assignment
Model Line for this Datasheet
Text Version of Document
156.250000 MHz Crystal XPP536156.250000I Oscillator Datasheet Addendum General Configuration Parameter Value
Jitter < 150 fs Package 5 x 3.2 mm Output Frequency 156.250000 MHz Frequency Stability ± 25 ppm VDD Voltage 3.3 V Output Type LVPECL Output Enable/Disable Position (E/D) Position Pin 1 Temperature Grade -40°C to +85°C
Pin Assignment Pin Number Pin Name Description
1 OE Output Enable (0 = output disabled; pulled high internally) 2 NC No connect 3 GND Connect to ground 4 Output 0 Output 5 Output 0b Complementary output 6 VDD Supply voltage 7 SDA (NA) Serial data (Not active for XO mode) 8 SCL (NA) Serial Clock (Not active for XO mode)
Corporate Headquarters Sales Tech Support
6024 Silver Creek Valley Road 1-800-345-7015 or 408-284-8200 www.IDT.com/go/support San Jose, CA 95138 USA Fax: 408-284-2775 www.IDT.com www.IDT.com/go/sales DISCLAIMER Integrated Device Technology, Inc. (IDT) and its affiliated companies (herein referred to as “IDT”) reserve the right to modify the products and/or specifications described herein at any time, without notice, at IDT's sole discretion. Performance specifications and operating parameters of the described products are d etermined in an independent state and are not guaranteed to perform the same way when installed in customer products. The information contained herein is provided without representation or warranty of a ny kind, whether express or implied, including, but not limited to, the suitability of IDT's products for any particular purpose, an implied warranty of merchantability, or non-infringement of the intellectual property rights of others. This document is presented only as a guide and does not convey any license under intellectual property rights of IDT or any third parties. IDT's products are not intended for use in applications involving extreme environmental conditions or in life support systems or similar devices where the failure or malfunction of an IDT product can be reasonably expected to significantly affect the health or safety of users. Anyone using an IDT product in such a manner does so at their own risk, absent an express, written agreement by IDT. Integrated Device Technology, IDT and the IDT logo are trademarks or registered trademarks of IDT and its subsidiaries in the United States and other countries. Other trademarks used herein are the property of IDT or their respective third party owners. For datasheet type definitions and a glossary of common terms, visit www.idt.com/go/glossary. All contents of this document are copyright of Integrated Device Technology, Inc. All rights reserved. ©2019 Integrated Device Technology, Inc. 1 May 17, 2019
