Datasheet NTE6809 - NTE Electronics IC, 8 bit MPU, 4 MHz, DIP-40

Detailed Description

Manufacturer: NTE Electronics

Description: IC, 8 bit MPU, 4 MHz, DIP-40

Download Data Sheet

Docket:
NTE6809 & NTE6809E Integrated Circuit NMOS, 8­Bit Microprocessor (MPU)
Description: The NTE6809 and NTE6809E are revolutionary high performance 8­bit microprocessors in 40­Lead DIP type packages which support modern programming techniques such as position independece, reentrancy, and modular programming.

The basic instructions of any computer are greatly enhanced by the presence of powerful addressing modes. The NTE6809 and NTE6809E have the most complete set of addressing modes available on any 8­bit microprocessor today. These devices contain hardware and software features which make them ideal processors for higher level language execution or standard controller applications. External clock inputs are provided on the NTE6809E to allow synchronization with peripherals, systems, or other MPUs. Architectural Features: D Two 16­Bit Index Registers D Two 16­Bit Indexable Stack Pointers D Two 8­Bit Accumulators can be Concatenated to Form One 16­Bit Accumulator D Direct Page Register Allo

Specifications:

• CPU Speed: 4 MHz
• Clock Frequency: 4 MHz
• Core Size: 8 bit
• Frequency: 4 MHz
• Number of Pins: 40
• Operating Temperature Range: 0°C to +70°C
• Package / Case: DIP
• Supply Voltage Range: 4.75 V to 5.25 V
