Data Sheet ADA4891-1/ADA4891-2/ADA4891-3/ADA4891-4 ABSOLUTE MAXIMUM RATINGS Table 3.
To ensure proper operation, it is necessary to observe the maxi-
Parameter Rating
mum power derating curves shown in Figure 6. These curves are derived by setting T Supply Voltage 6 V J = 150°C in Equation 1. Figure 6 shows the maximum safe power dissipation in the package vs. the Input Voltage (Common Mode) −VS − 0.5 V to +VS ambient temperature on a JEDEC standard 4-layer board. Differential Input Voltage ±VS Storage Temperature Range −65°C to +125°C
2.0 TJ = 150°C
Operating Temperature Range −40°C to +125°C
14-LEAD TSSOP
Lead Temperature (Soldering, 10 sec) 300°C
W) ( 1.5
Stresses at or above those listed under Absolute Maximum
TION 8-LEAD SOIC_N PA
Ratings may cause permanent damage to the product. This is a
ISSI
stress rating only; functional operation of the product at these
D 1.0
or any other conditions above those indicated in the operational
ER 8-LEAD MSOP W
section of this specification is not implied. Operation beyond
M PO 5-LEAD SOT-23
the maximum operating conditions for extended periods may
MU 0.5 XI
affect product reliability.
14-LEAD SOIC_N MA MAXIMUM POWER DISSIPATION 0
The maximum power that can be safely dissipated by the
–55 –35 –15 5 25 45 65 85 105 125
002 ADA4891-1/ADA4891-2/ADA4891-3/ADA4891-4 is limited
AMBIENT TEMPERATURE (°C)
08054- by the associated rise in junction temperature. The maximum Figure 6. Maximum Power Dissipation vs. Ambient Temperature safe junction temperature for plastic encapsulated devices is Table 4 lists the thermal resistance (θJA) for each ADA4891-1/ determined by the glass transition temperature of the plastic, ADA4891-2/ADA4891-3/ADA4891-4 package. approximately 150°C. Temporarily exceeding this limit can cause a shift in parametric performance due to a change in the
Table 4.
stresses exerted on the die by the package. Exceeding a junction
Package Type θJA Unit
temperature of 175°C for an extended period can result in 5-Lead SOT-23 146 °C/W device failure. 8-Lead SOIC_N 115 °C/W The still-air thermal properties of the package (θ 8-Lead MSOP 133 °C/W JA), the ambient temperature (T 14-Lead SOIC_N 162 °C/W A), and the total power dissipated in the package (P 14-Lead TSSOP 108 °C/W D) can be used to determine the junction temperature of the die. The junction temperature can be calculated as T
