ADVFC32 UNIPOLAR V/F, POSITIVE INPUT VOLTAGE
replaced during the remainder of the cycle to return the integra- When operated as a V/F converter, the transformation from tor to its original voltage. Since the charge taken out of C2 is voltage to frequency is based on a comparison of input signal equal to the charge that is put on C2 every cycle, magnitude to the 1 mA internal current source.  1  A more complete understanding of the ADVFC32 requires a (1 mA – I – t IN) × tOS = IIN × OS  F  close examination of the internal circuitry of this part. Consider OUT the operation of the ADVFC32 when connected as shown in or, rearranging terms, Figure 1. At the start of a cycle, a current proportional to the IIN FOUT = 1mA × t OS The complete transfer equation can now be derived by substi- tuting IIN = VIN/RIN and the equation relating C1 and tOS. The final equation describing ADVFC32 operation is: VIIN / RIN 1mA × C + 44 pF ( )×6.7kΩ 1 Components should be selected to optimize performance over the desired input voltage and output frequency range using the equations listed below: 3.7 ×107 pF / sec – 44 pF F OUT FS 10–4 Farads / sec C 1000 pF minimum ( ) 2 = F Figure 1. Connection Diagram for V/F Conversion, OUT FS Positive Input Voltage VIN FS input voltage flows through R3 and R1 to charge integration RIN = 0.25mA capacitor C2. As charge builds up on C2, the output voltage of the input amplifier decreases. When the amplifier output volt- +VLOGIC R age (Pin 13) crosses ground (see Figure 2 at time t 2 ≥ 1), the 8 mA comparator triggers a one shot whose time period is determined Both RIN and C1 should have very low temperature coefficients by capacitor C1. Specifically, the one shot time period (in nano- as changes in their values will result in a proportionate change seconds) is: in the V/F transfer function. Other component values and tem- tOS ≅ (Cl + 44 pF) × 6.7 kΩ perature coefficients are not critical.
Table I. Suggested Values for C1, RIN and C2 VIN FS FOUT FS C1 RIN C2
1 V 10 kHz 3650 pF 4.0 kΩ 0.01 µF 10 V 10 kHz 3650 pF 40 kΩ 0.01 µF 1 V 100 kHz 330 pF 4.0 kΩ 1000 pF 10 V 100 kHz 330 pF 40 kΩ 1000 pF
ORDERING GUIDE Part Gain Tempco Temp Range Package Number1 ppm/
ⴗ
C
ⴗ
C Option
ADVFC32KN ±75 typ 0 to 70 14-Pin Plastic DIP ADVFC32BH ±100 max –25 to +85 TO-100 Figure 2. Voltage-to-Frequency Conversion Waveforms ADVFC32SH ±150 max –55 to +125 TO-100 During this period, a current of (1 mA – IIN) flows out of the NOTE integration capacitor. The total amount of charge depleted 1For details on grade and package offerings screened in accordance with MIL-STD-883, during one cycle is, therefore (1 mA – IIN) × tOS. This charge is refer to the Analog Devices Military Products Databook or current ADVFC32/883B data sheet.
