L165
3A POWER OPERATIONAL AMPLIFIER ■ OUTPUT CURRENT UP TO 3A ■ LARGE COMMON-MODE AND DIFFERENTIAL MODE RANGES ■ SOA PROTECTION ■ THERMAL PROTECTION ■ ± 18V SUPPLY
DESCRIPTION Pentawatt V
The L165 is a monolithic integrated circuit in Pen- tawatt® package, intended for use as power oper-
ORDERING NUMBER: L165V
ational amplifier in a wide range of applications, including servo amplifiers and power supplies. The high gain and high output power capability provide superiore performance wherever an operational amplifier/power booster combination is required.
APPLICATION CIRCUITS Figure 1. Gain > 10. Figure 2. Unity gain configuration.
Obsolete Product(s) - Obsolete Product(s) July 2003 1/9
