LTM9013
DynaMic accuracy The
l
denotes the specifications which apply over the full operating temperature range, otherwise specifications are at TA = 25°C. PRF = –5dBm, PLO = 0dBm (Notes 5, 7) unless otherwise noted. SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
IIP3 Input 3rd Order Intercept, 1 Tone RF = 2140MHz, LO = 1990MHz 30 dBm IIP2 Input 2nd Order Intercept, 1 Tone RF = 2140MHz, LO = 1990MHz 56 dBm SNR Signal-to-Noise Ratio at –1dBFS RF = 2140MHz, LO = 1990MHz (Figure 14) 59 dBFS fIF = 150MHz (Note 6) l 59 62 dBFS SFDR Spurious Free Dynamic Range RF = 2140MHz, LO = 1990MHz (Figure 14) 65 dB 2nd or 3rd Harmonic fIF = 150MHz (Note 6) l 60 70 dB Spurious Free Dynamic Range RF = 2140MHz, LO = 1990MHz (Figure 14) 75 dB 4th or Higher fIF = 150MHz (Note 6) 80 dB S/(N+D) Signal-to-Noise Plus Distortion Ratio RF = 2140MHz, LO = 1990MHz (Figure 14) 58 dBFS fIF = 150MHz (Note 6) l 58 61 dBFS IMD3 Intermodulation Distortion at –7dBFS per RF = 2140MHz and 2141MHz, LO = 1990MHz 66 dB Tone (Figure 14)
analog inpuTs anD ouTpuTs The
l
denotes the specifications which apply over the full operating temperature range, otherwise specifications are at TA = 25°C. (Notes 5, 7) SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS Demodulator Adjust Inputs (IP2I, IP2Q)
Input Voltage 0 1.3 V Input Impedance 2||1 kΩ||pF Settling Time For Step Input; Output with 90% of Final Value 2 μs
